Description
Designed for the construction of optical distribution and subscriber sections where greater fiber capacity is required in a compact cable design. The model includes 24 G652D single-mode fibers arranged in a 2×12 configuration, allowing for the support of more optical lines through a single cable.
The design incorporates two FRP reinforcing elements with a diameter of Ø2.00 mm, which enhance the cable’s mechanical strength during installation and operation along the route. The flat design is practical for FTTx distribution in building and last-mile network segments.
Technical Specifications
| Armor | Unreinforced |
|---|---|
| Cable Type | FTTH |
| Fiber Type | G652D |
| Length (m) | 2,000 m |
| Manufacturers | DANIMPEX |
| Number of Fibers | 24F |
| Porter | 2x FRP |
| Tubes | 2×12 |
Files
There are no files available.
FTTH flat cable, 24 fibers, multi-tube (2×12 fibers), with 2×2.00 mm FRP, G652D, SM, 2 km/reel
Price
0.48 €
Price excluding VAT:
0.40 €
Количество:
Secure Payment
Request a B2B Quote
Free shipping on orders over 400 euros
Warranty on All Products
